Raster Universal Formwork proves its versatility, adaptability and flexibility on foundations, walls, shafts, curves, columns or joists on a variety of construction sites worldwide. A balanced element sorting allows an optimal adaptation of the formwork to all floor plans and cross sections. Can be used both in the small area and for the large surface system (GE) expandable.
Properties
- The crane-independent universal formwork
- Centimeter accurate and time-saving
- Simply unbeatable in the foundation area
- Typical applications: foundations, walls, columns, beams, shafts, curves (polygons), GaLa-Bau
- Flat steel frame guarantees robustness and longevity
- Construction height: 7.5cm
- Cladding: 15 mm birch plywood, 11-layered
- Grid elements 62.5cm, 75cm, 100cm, 125cm, 150cm,
